系統描述

現場站數據采集器采用研華adam-4017+模擬量采集模塊，每個模塊8通道模擬量，4個adam-4017+可以滿足24路4～20ma模擬信號的采集，通過modbus rtu協議傳輸數據至現場控制器。

控制器使用研華uno-1170工業嵌入式計算機。此控制器搭配320g硬盤，可以安  裝xp操作系統�？刂破鲀�(nèi)嵌webaccess軟件，通過rs-485整體實現對現場24路信號的收集，15天存儲及斷點續傳的功能。

控制器搭載研華遠程設備管理軟件diaganywhere軟件，可在監控中心實時監控控制器的運行狀態，對控制器的遠程維護，達到遠程管理的作用。

現場顯示部分使用研華webop-2070k工業可編程人機界面，實現現場觸控及調試等功能。

上層監控中心服務器也搭載研華專業版5000點webaccess基于b/s的組態軟件，實現車間的整體監控。與現場控制器通過opc方式進行通訊，實現網絡通訊恢復之后的斷點續傳功能。同時，可以通過標準的odbc接口連接數據庫服務器，進行歷史數據的存儲和調用；

通過已成型的組態工程，直接可以拖拽工程的不同畫面到需求的顯示屏之中，實現4個工程畫面的報警、狀態、報表等的展示。

項目實施
